QuadMarka – 240v 316 Stainless Steel GU10 IP67 Recessed Light 4 Windows 360 Degree Of Light
Codes,
The QuadMarka is supplied with approx. 3m of 3 core H05RNF cable. This longer cable length gives the option of a 6m space between two lights should it be needed, and could cut down the number of cable joins in outdoor lighting installation. Light can also be spread to a wider area with longer cable length.
CARE OF STAINLESS STEEL – TIPS
Contrary to popular belief, Stainless steel needs looking after; especially in exposed and coastal areas. If not
cleaning on a regular basis, the acid that is ever present in the air ( and salt in coastal areas) will affect
the surface causing pitting and even rust like staining (known as ‘Tea staining’ ) to appear.
To keep your lights looking good, simply wipe clean the outside with a damp cloth and then dry once a month, (more
frequently in coastal areas). Specialist stainless steel cleaning products can be used (We recommend and stock
‘Kilrock stainless steel cleaner’) but never use an ABRASIVE cleaner. In extreme conditions we recommend applying
2 coats of Clear lacquer to protect the steel surface. (We recommend and stock ‘Simoniz’ clear lacquer).
240v IN-GROUND LIGHTS
240v fittings can be affected by damp conditions, typically when located outdoors. When a fitting is located outside
in the cold air combined with the heat produced by the lamp inside, it is inevitable that condensation will occur,
just as it does on bedroom windows in the home. If too much condensation is produced, this could result in the
fitting tripping, especially in these types of fittings where a drainage hole is not possible. To combat this,
we include silica gel with all Quadmarka 240v in-ground lights to soak up any excess moisture – these should
not be removed but replaced periodically and fittings checked. If any water is sitting in the fitting, this should
be tipped out and the fitting safely dried out. Condensation can be more prominent when the fitting has been
opened on a damp day, as the damp air will then be trapped inside when re-sealed. Therefore it is recommended
that any maintenance, including changing bulbs, is performed on a dry day. An additional practice to be put in
place is to apply Lithium Grease to the bulb holder / bulb which acts as an additional seal to prevent tripping.
Although this prevents tripping, the fittings will still need to be checked and dried out should water sit inside
the fitting. For extra protection, the Quadmarka can also be filled with Wiska Gel (electrical insulation).
