Pro Solar SOL-ICON – Two Sided PIR Black Solar Path Light In Warm White Or Cool White LEDs

The Sol-Icon PIR Solar Path Light is a very unique design. Not only is it super slimline, it is also a two sided path light,
designed to illuminate in both directions independently. From a sideways view, the path light is almost non-existent.
Each side has a control button which selects the mode for the corresponding side of 10W LEDs (1000 lumens per side –
total 2000 lm). A PIR is also located on both sides which are triggered individually and illuminate the LEDs on the relevant
side.

A combination of the following modes can be selected on each side: PIR mode, constant low level (dusk to dawn) and off.

Their mounting position will determine which mode is the best option.

The high quality monocrystalline solar panel is also double sided. The main benefit of this is that when the sun moves around
it will always shine on one side of the solar panel for optimum charging. Set in 2 layers of toughened glass, the integrated
solar panel is extremely robust with an IK Rating of IK08. The one solar panel charges the replaceable LiFePO4 lithium
batteries, which, in turn, power both sets of LEDs. The batteries will retain their charge for even longer when only
one set of LEDs are in use. Each side accommodates 10W long life LEDs with a high lumen output of 1000 lumens. When
both sets are illuminated, this generates a huge 2000 lumens output. Both warm white and daylight white options are available.

MODES

1. PIR Mode – Full brightness when PIR triggered, then returns to 15% brightness after 20 seconds of no movement
2. Constant Light (dusk to dawn) – Constant illumination at 50% brightness
3. Off

The Sol-Icon Solar PIR Path Light is both easy and safe to install. The multiple mounting options and lack of wiring also
make it very versatile when it comes to positioning. Eco Solar lighting converts natural energy into electrical current,
with the added benefit of it being completely free to run.

Note, although the Pro-Solar Range incorporate high quality technology, on particularly dull days the fittings may not charge
to their highest capacity. As a result, illumination is not guaranteed throughout the entire night, but highly likely
on sunny days.

Wattage 2 x 10w LEDs SMD 3030 (40pcs) LED Chips

MOUNTING

Multiple mounting options come with this PIR Solar Path Light. The removable, internal mount secures directly onto any flat
surface. It also mounts onto concrete with the supplied anchor bolts. In addition, two substantial aluminium 4 fin ground
spikes allow mounting into soft ground. These ground spikes simply attach to the internal surface mount.
