Ikon PRO CCT 3000K/4000K 45mm Kit IP67 0.75W Cct

An addition to the popular Ikon PRO recessed LED decking kit range, within each head there is the choice of 3000K or 4000K
in one kit or the other kit offers 6500K or blue. Using the unique design of removable and interchangeable heads to change
colour, you simply lift the LED head out of the connector, turn the head 180° and reinsert into the loom. Designed to be
fitted and wired during the decking build stage without the heads, the supplied rubber caps protect the fitting from the
elements until the decking is complete. Available in a variety of sizes and colours.



• Suitable for indoor or outdoor use
• Polished stainless steel & clear pc
• Constructed from stainless steel (304) & polycarbonate
• Super bright SMD LED technology
• Innovative new fitting method
• Improved lens design
• Complete with LED driver
• 10 x 0.75W LED module (SMD 4014) CCT (Included)
• K: 3000/4000 Lm: 410 Lm/W: 55
• IP67
• Proj: 1mm Dia: 45mm
• Class 3
• Cut hole Dia: 32mm
• 2 year warranty
• Weight: 1.1 Kg

 The Kit contains: • 1 x IP67 rated driver with 3 metres of mains cable and mains plug.

 1 x 5m extension
cable

 2 x 5 LED head looms (total length 7.5m per loom)

10 x end plugs Power Supply: 220-240V 50Hz. Output: 12V DC 15W
Max. Constant voltage Lamp:

 45mm – Warm white (3000K)/Cool white (4000K)

These kits are supplied with removable and interchangeable heads. Arrow on LED head
unit is connected to arrow 1 on connector = Warm white (3000K) – Arrow on LED head unit is connected to arrow 2 on connector
= Cool white (4000K).
