0.75mm 2 Core Rubber Cable (12V) – 25m Reel

0.75mm 2 Core Rubber Cable (12V) – 25m or 50m Reel

This 0.75mm 2 core cable will connect a number of 12V garden lights together via junction boxes, or direct to transformers,
to create a complete 12v system. It is ideal for outdoor applications due to it being both water resistant and oil resistance.
To prevent voltage drop, try to keep cable runs as short as possible (up to 25m), or increase cable thickness (see below).
Available in  25m and 50m cable lengths.

This H05BN4-F rubber cable is extra flexible even when installed in temperatures less than zero degrees. The copper stranded
conductor cables are insulated individually interally. In addition, a tough yet flexible neoprene rubber sheath surrounds
both cables, protecting from damage.

Please note this rubber cable is not armoured so position with care. We recommend that all 2 core cable is protected in conduit.
This not only protects the cable from accidental damage, but also from rodents, acidic soil, weedkiller and other chemicals,
and also the sun.

Cable length 25m or 50m.  Core cable 2 x  0.75mm² (12v) – Rubber. Conductor  – Copper.  Overall diameter of cable 6.4mm.

Sheath – Neoprene (Rubber). Sheath thickness 0.6 – 1mm. Operating temperature range  -30°C to +60°C.

Voltage – 500v Max.(Suitable for use with 12v lighting systems).

Additional information – VDE approved, RoHS compliant.

Type – H05BN4-F
